Product Description
Formerly: SIL flex / CAPCELL HD100
The most compressible filler board for expansion joints
DURA board HD100' is a high performance cross linked,
pre-moulded, compressible joint filler board. It is readily compressible filler board that ensures low load transfer DURA board HD 100 (expansion joint filler board) is a non-bituminous superior alternative to bitumen boards
Features :
- Closed cell hence negligible water / water vapour absorption
- Resilient - recovers more than 96%
- Excellent chemical resistance
- Thermally stable(from - 40 °C to + 70 °C)
- Bitumen free
- Easy to use
- Rot proof and bacteria resistant
Applications :
- Structural expansion joint filler for concrete brick and block work in concrete highways, airport runways parking areas, industrial flooring & taxi tracks etc.
- Isolation to infill panels
- Bridge decks, abutments, pier hinge joints etc.
- As a backup support for sealant
- Expansion joints in concrete highways, airport runways, taxi tracks etc.
- Expansion joints in parking areas, industrial flooring etc.
- Water retaining and water excluding structures
Product Details:
| Resilient | Recovers more than 96% |
| Thermally stable Temperature | From - 40 Degree C to + 70 Degree C) |
| Brand | Supreme |
Exceptional Durability for InfrastructureEngineered to perform under heavy vehicular and pedestrian loads, the Supreme Non Bituminous Expansion Joint Filler Board resists decay, chemicals, and water incursion. Its robust polyethylene closed cell foam composition delivers resilient performanceideal for bridges, highways, airport runways, and industrial floorsensuring longevity and structural integrity.
Eco-Friendly and Maintenance-Free SolutionThis filler board is CFC and HCFC free, making it environmentally safe. Odorless and self-extinguishing, it accommodates both manual and machine installation for versatile project needs. Its non-bituminous nature allows for clean handling, and it requires no ongoing maintenance, saving time and costs for operators.
FAQs of Supreme Non Bituminous Expansion Joint Filler Board:
Q: How is Supreme Non Bituminous Expansion Joint Filler Board installed in construction projects?
A: The board is manually placed into expansion gaps in structures such as bridges, highways, or runways. Installation is straightforward and may be performed by hand or with machinery. Its lightweight sheet form simplifies positioning and handling during projects.
Q: What are the main benefits of using this expansion joint filler compared to bituminous alternatives?
A: Supreme Non Bituminous Expansion Joint Filler Board offers superior resilience, is rot proof, chemically resistant, and doesnt absorb water. Additionally, it is maintenance-free, odorless, self-extinguishing, and environmentally safe, distinguishing it from traditional bituminous fillers which may degrade or emit odors over time.
Q: Where can the Supreme Non Bituminous Expansion Joint Filler Board be used?
A: It is suitable for various infrastructure applications including bridge decks, concrete roads, airport runways, parking lots, industrial floors, and building expansion joints. Its high strength and weather resistance make it ideal for locations exposed to heavy loads and extreme environments.
Q: What is the process for customizing the size and thickness of filler boards?
A: Manufacturers supply these boards in standard sizes of 1220 mm x 2440 mm and thicknesses of 10 mm, 12 mm, 20 mm, 25 mm, and 50 mm. Custom sizes and thicknesses may be produced upon request to match specific project requirements, ensuring precise fitment for any application.
Q: When should this expansion joint filler be selected for new or repair projects?
A: Choose Supreme Non Bituminous Expansion Joint Filler Board when you require long-term durability, excellent resilience against deformation, high moisture and chemical resistance, and a maintenance-free, environmentally safe solution for demanding constructions such as bridges, roadways, and industrial installations.
Q: What makes this board environmentally safe and suitable for modern infrastructure?
A: It is completely free from CFCs and HCFCs, making it non-toxic and safe for sensitive environments. Its non-bituminous, odorless, and recyclable nature ensures minimal environmental impact, aligning with sustainable construction practices.
